MS series three phase motor

MS

Supply Ability:

10000 / Day

Country of Origin:

TAIZHOU, CHINA

Quantity:

Contact Now

add to cart

MS series three phase asynchronous induction electric motor

Operating Conditions
Ambient temperature: -15ºC < Θ < 40ºC
Altitude: not exceeding 1000m
Rated voltage: 380V
Rated frequency: 50HZ,60HZ
Protection class: IP54,IP55
Insulation class: B,F
Cooling method: ICO141
Duty:S1 (continuous)

Technical Data

Model	Output		Current (A)	Speed (r/min)	Eff. (%)	Power factor	Tstart /Tn	Ist/ In
Model	KW	HP	Current (A)	Speed (r/min)	Eff. (%)	Power factor	Tstart /Tn	Ist/ In
380V/50HZ Synchronous Speed 3000 r/min (2 poles)
MS56M1-2	0.09	0.12	0.3	2700	58	0.78	2.2	5.5	2.2
MS56M2-2	0.12	0.18	0.38	2700	60	0.79	2.2	5.5	2.2
MS63M1-2	0.18	0.25	0.53	2720	63	0.8	2.2	5.5	2.2
MS63M2-2	0.25	0.33	0.69	2720	65	0.81	2.2	5.5	2.2
MS71M1-2	0.37	0.5	0.99	2740	66	0.81	2.2	6.1	2.2
MS71M2-2	0.55	0.75	1.4	2740	71	0.82	2.2	6.1	2.3
MS80M1-2	0.75	1	1.83	2835	77.4	0.83	2.2	6.1	2.3
MS80M2-2	1.1	1.5	2.58	2835	79.6	0.84	2.2	7	2.3
MS90S-2	1.5	2	3.43	2845	81.3	0.84	2.2	7	2.3
MS90L-2	2.2	3	4.85	2845	83.2	0.85	2.2	7	2.3
MS100L-2	3	4	6.31	2875	84.6	0.87	2.2	7	2.3
MS112M-2	4	5.5	8.1	2895	85.8	0.88	2.2	7.5	2.3
MS132S1-2	5.5	7.5	11	2905	87	0.88	2.2	7.5	2.3
MS132S2-2	7.5	10	14.9	2905	88.1	0.88	2.2	7.5	2.3
MS160M1-2	11	15	21.3	2935	89.4	0.89	2.2	7.5	2.3
MS160M2-2	15	20	28.8	2935	90.3	0.89	2.2	7.5	2.3
MS160L-2	18.5	25	34.7	2935	90.9	0.9	2.2	7.5	2.3
380V/50HZ Synchronous Speed 1500 r/min (4 poles)
MS56M1-4	0.06	0.08	0.26	1300	53	0.7	2.1	5.2	2.2
MS56M2-4	0.09	0.12	0.35	1300	55	0.71	2.1	5.2	2.2
MS63M1-4	0.12	0.18	0.42	1310	57	0.72	2.1	5.2	2.2
MS63M2-4	0.18	0.25	0.62	1310	60	0.73	2.1	5.2	2.2
MS71M1-4	0.25	0.33	0.79	1330	65	0.74	2.1	5.2	2.2
MS71M2-4	0.37	0.5	1.12	1330	67	0.75	2.1	5.2	2.2
MS80M1-4	0.55	0.75	1.57	1395	71	0.75	2.4	5.2	2.3
MS80M2-4	0.75	1	2.03	1395	79.6	0.76	2.3	6	2.3
MS90S-4	1.1	1.5	2.89	1405	81.4	0.77	2.3	6	2.3
MS90L-4	1.5	2	3.7	1405	82.8	0.79	2.3	6	2.3
MS100L1-4	2.2	3	5.16	1435	84.3	0.81	2.3	7	2.3
MS100L2-4	3	4	6.78	1435	85.5	0.82	2.3	7	2.3
MS112M-4	4	5.5	8.8	1445	86.6	0.82	2.3	7	2.3
MS132S-4	5.5	7.5	11.7	1445	87.7	0.83	2.3	7	2.3
MS132M-4	7.5	10	15.6	1445	88.7	0.84	2.3	7	2.3
MS160M-4	11	15	22.3	1465	89.8	0.84	2.2	7	2.3
MS160L-4	15	20	30.1	1465	90.6	0.85	2.2	7.5	2.3
380V/50HZ Synchronous Speed 1000 r/min (6 poles)
MS71M1-6	0.18	0.25	0.74	850	56	0.66	1.9	4	2
MS71M2-6	0.25	0.33	0.95	850	59	0.68	1.9	4	2
MS80M1-6	0.37	0.5	1.3	895		0.7	1.9	4.7	2
					62

MS80M2-6	0.55	0.75	1.79	895	65	0.72	1.9	4.7	2.1
MS90S-6	0.75	1	2.29	915	75.9	0.72	2	5.5	2.1
MS90L-6	1.1	1.5	3.18	915	78.1	0.73	2	5.5	2.2
MS100L-6	1.5	2	3.94	945	79.8	0.75	2	5.5	2.1
MS112M-6	2.2	3	5.6	945	81.8	0.73	2	6.5	2.1
MS132S-6	3	4	7.4	965	83.3	0.76	2.1	6.5	2.1
MS132M1-6	4	5.5	9.8	965	84.6	0.76	2.1	6.5	2.1
MS132M2-6	5.5	7.5	12.9	965	86	0.77	2.1	6.5	2.1
MS160M-6	7.5	10	17	975	87.2	0.77	2	6.5	2.1
MS160L-6	11	15	24.2	975	88.7	0.78	2	6.5	2.1
380V/50HZ Synchronous Speed 750 r/min (8 poles)
MS80M1-8	0.18	0.25	0.88	630	51	0.61	1.8	4	1.9
MS80M2-8	0.25	0.33	1.15	640	54	0.61	1.8	4	1.9
MS90S-8	0.37	0.5	1.49	660	62	0.61	1.8	4	1.9
MS90L-8	0.55	0.75	2.18	660	63	0.61	1.8	4	2
MS100L1-8	0.75	1	2.17	690	71	0.67	1.8	4	2
MS100L2-8	1.1	1.5	2.39	690	73	0.69	1.8	5	2
MS112M-8	1.5	2	4.5	680	75	0.69	1.8	5	2
MS132S-8	2.2	3	6	710	78	0.71	1.8	6	2
MS132M-8	3	4	7.9	710	79	0.73	1.8	6	2
MS160M1-8	4	5.5	10.3	720	81	0.73	1.9	6	2
MS160M2-8	5.5	7.5	13.6	720	83	0.74	2	6	2
MS160L-8	7.5	10	17.8	720	85	0.75	2	6	2
