MC Series Aluminum Housing Single-Phase Capacitor-Started Induction Induction Motor

Products

MCseries single-phase asynchronous electric aluminum capacitors start using the latest design from high quality material relevant IEC standards developed from has a good performance, reliable operation, safety, aesthetic appearance, Easy maintenance, noise, vibration, light weight, simple structure,a series of advantages.MCseries motors are suitable for air compressors,pumps, refrigeration, medical instruments, equipment and other needs fully loaded starter machine.

OPERATING CONDITIONS

Ambient temperature:-15ºC< θ<40ºC

Altitude:Not exceeding 1000m Rated

Rated voltage:220V、100V-240V

Protection class: IP44、IP54

Insulation Class:B、F、H

method:ICO141

Duty:S1(continuous)

Technical Data

Type	Output		Voltage	Rated speed (r/min)	Rated current (A)	Eff(%)	Power factor	Locked rotor current	Locked rotor torque	Pull out torque
	Kw	Hp						Rated torque	Rated torque	Rated torque
MC80A-2	0.37	0.5	220	2840	3.5	66.0	0.77	3	6.5	1.8
MC80B-2	0.55	0.75	220	2850	5.04	67.0	0.79	3	6.5	1.8
MC80C-2	0.75	1	220	2850	6.68	68.0	0.80	3	6.5	1.8
MC90S-2	1.1	1.5	220	2850	8.93	70.0	0.80	2.8	7.0	1.8
MC90L-2	1.5	2	220	2870	11.4	73.0	0.82	2.8	7.0	1.8
MC100L-2	2.2	3	220	2900	16.5	74.0	0.82	2.5	7.0	1.8
MC112M1-2	3	4	220	2900	21.4	76.0	0.84	2.2	7.0	1.8
MC112M2-2	3.7	5	220	2900	24.8	79.0	0.86	2.2	7.0	1.8
MC1325-2	3.7	5	220	2900	24.8	79.0	0.86	2.2	7.0	1.8
MC80A-4	0.25	0.33	220	1400	3.52	52.0	0.62	3	6	1.8
MC80B-4	0.37	0.5	220	1400	4.69	56.0	0.64	3	6	1.8
MC80C-4	0.55	0.75	220	1400	6.0	60.0	0.65	3	6	1.8
MC905-4	0.75	1	220	1400	7.5	63.0	0.72	2.8	6.5	1.8
MC90L-4	1.1	1.5	220	1420	10.4	67.0	0.72	2.8	6.5	1.8
MC100L-4	1.5	2	220	1440	13.0	72.0	0.73	2.8	6.5	1.8
MC112M-4	2.2	3	220	1450	18.5	73.0	0.74	2.5	6.5	1.8
MC132SA-4	3	4	220	1450	22.4	76.0	0.80	2.2	6.5	1.8
MC132SB-4	3.7	5	220	1450	26.0	79.0	0.82	2.2	6.5	1.8
